6.50 Lac - 7.50 Lac / piece

1 piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Type Metal Milling
Brand Name ESSKAY
Reverse Rotation No
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Material
Cast Iron
Warranty
1 Year
Certification
ISO 9001:2015
Shape
Square
Phase
Three Phase
Corrosion Resistance
No
Driven Type
Mechanical
Condition
New
Operating Mode
Automatic
Power
3-6kw
Finishing
Polished
Packaging Type
Wooden Box Packing
Country of Origin
India
Product Code
EVMA-2
Port
SAHNEWAL
Payment Terms
T/T
Delivery Time
30 DAYS

Esskay Lathe & Machine Tools is amongst the top vertical milling machine manufacturers in India and deals in the best quality vertical milling machines. The vertical milling machine is a precisely designed tool used for different types of operations like grooves, slots, a flat surface, etc.


Quality-approved components and advanced technology are used to manufacture our vertical milling machines. These machines come with advanced features and can be used to do complex operations and cut the workpiece in any direction.


The offered machines are highly appreciated for their robust construction, excellent output, uninterrupted performance, easy operation, smooth rotation, precision, and low maintenance. Our quality control specialists make all these machines go through several quality checks to provide only machines with zero manufacturing defects.


We make our machines available at reasonable prices so that everyone can afford them. Rely on us and get the best deal on our vertical milling machines.

Yes! I am interested


Specifications

Model No EVMA - 2 EVMA - 3 EVMA - 4 EVMA - 5 EVMA - 6
Working Space 1300 x 300 1400 x 300 1600 x 350 1800 x 400 2000 x 50mm
No. & Width of T Nut 3.16 3.22 T NUT 3.22 T NUT 3.22 T NUT 3.22 T NUT
Centre Distance Between T Slots 70 80 85 90 95
Longitudinal Travel By Power X 700 800 1000 1200 1300mm
Cross Traverse By Power Y 215 260 340 380 450mm
Vertical Travel By Power Z 450 510 600 650 700mm
Min. Distance From Left Hand Table End to Spindle Center 250 300 350 400 450
No. of Speeds 12 12 12 12 12
Speed Range 40-1200 40-1200 40-1200 40-1200 40-1200
Spindle Nose ISO - 40 ISO - 40 ISO - 40 ISO - 50 ISO - 50
Min,/ Max. Distance, Centre Milling Spindle/ Lower Face of Milling Spindle to Table Top Surface 40-450 0-510 0-600 0-650 0-700
Distance Spindle Centre to Column 320 350 370 400 500
Swivel of Milling Head On Either Side 45o 45o 45o 45o 45o
FEEDS FEEDS
No. of Feeds 18 18 18 18 18
Feed Range : Long & Cross 23-420 23-420 23-420 23-420 23-420
Vertical 25628 25628 25628 25628 25628
Rapid Traverse : Long Cross 1050 1050 1050 1050 1050
Vertical 175 175 175 175 175
POWER POWER
Main Motor 3 H.P 5 H.P 7.5 H.P 10 H.P 12 H.P.
Feed Motor 2 H.P 2 H.P 3 H.P 3 H.P 3 H.P.
Coolant Motor 0.1 H.P. 0.1 H.P. 0.1 H.P. 0.1 H.P. 0.1 H.P.
